SPECIALFrom saving money through reduced heating costs to countermeasures against unpleasant dew condensation,
we offer many MADO-ECO Solutions!!
I want to keep my rooms warm by making an inventive change
around the windows of my home!
But I don't know what product to choose...
If this is the case for you, follow this chart and select the best MADO-ECO product for your needs.
Stick on your windowpane and improve the effect of heating
by shutting out cool air from outside with the air layer.
-
Insulation Film
for Windows, Transparent
(Tape + dryer)Natural lighting performance:
ExcellentCompatible glass
◯ ： Transparent sheet glass/Figured glass/Wired glass/Cloudy glass/Double glazing/Vacuum double glazing/Low emissivity (Low-E) glass such as heat absorbing / reflecting glass/Organic glass (acrylic sheet, etc.) - Line
-
Window Glass
Insulation Sheet, 7mm
(Water-activated)Compatible glass
◯ ： Transparent sheet glass △ ： Figured glass/Cloudy glass/Double glazing:For smooth surfaces: 〇 For uneven surfaces, please affix with a double-sided seal ✕ ： Wired glass/Vacuum double glazing/Low emissivity (Low-E) glass such as heat absorbing / reflecting glass/Organic glass (acrylic sheet, etc.):There is a risk that it may crack due to heat - Line
-
Window Glass
Insulation Sheet
(Heat-Generating Type)
(Water-activated)Compatible glass
◯ ： Transparent sheet glass △ ： Figured glass/Cloudy glass/Double glazing:For smooth surfaces: 〇 For uneven surfaces, please affix with a double-sided seal ✕ ： Wired glass/Vacuum double glazing/Low emissivity (Low-E) glass such as heat absorbing / reflecting glass/Organic glass (acrylic sheet, etc.):There is a risk that it may crack due to heat - Line
-
Window Glass
Insulation Sheet, 3.5mm
(Water-activated)Compatible glass
◯ ： Transparent sheet glass △ ： Figured glass/Cloudy glass/Double glazing:For smooth surfaces: 〇 For uneven surfaces, please affix with a double-sided seal ✕ ： Wired glass/Vacuum double glazing/Low emissivity (Low-E) glass such as heat absorbing / reflecting glass/Organic glass (acrylic sheet, etc.):There is a risk that it may crack due to heat - Line
- 1
- 2
- 3
- 4
-
Window Glass
Insulation Sheet, Pattern
(Water-activated)Compatible glass
◯ ： Transparent sheet glass △ ： Figured glass/Cloudy glass/Double glazing:For smooth surfaces: 〇 For uneven surfaces, please affix with a double-sided seal ✕ ： Wired glass/Vacuum double glazing/Low emissivity (Low-E) glass such as heat absorbing / reflecting glass/Organic glass (acrylic sheet, etc.):There is a risk that it may crack due to heat - Line
-
Window Glass
Insulation Sheet
(For uneven glass / adhesive)Compatible glass
◯ ： Transparent sheet glass/Figured glass/Cloudy glass/Double glazing:For smooth surfaces: 〇 For uneven surfaces, please affix with a double-sided seal ✕ ： Wired glass/Vacuum double glazing/Low emissivity (Low-E) glass such as heat absorbing / reflecting glass/Organic glass (acrylic sheet, etc.):There is a risk that it may crack due to heat - Line
-
Window Glass
Insulation Sheet
for Smooth Glass
(For smooth glass / adhesive)Compatible glass
◯ ： Transparent sheet glass △ ： Figured glass/Cloudy glass/Double glazing:For smooth surfaces: 〇 For uneven surfaces, please affix with a double-sided seal ✕ ： Wired glass/Vacuum double glazing/Low emissivity (Low-E) glass such as heat absorbing / reflecting glass/Organic glass (acrylic sheet, etc.):There is a risk that it may crack due to heat - Line
-
Window Glass
Insulation Sheet, Transparent
(Water-activated)Natural lighting performance:
ExcellentCompatible glass
◯ ： Transparent sheet glass △ ： Figured glass/Cloudy glass/Double glazing:For smooth surfaces: 〇 For uneven surfaces, please affix with a double-sided seal ✕ ： Wired glass/Vacuum double glazing/Low emissivity (Low-E) glass such as heat absorbing / reflecting glass/Organic glass (acrylic sheet, etc.):There is a risk that it may crack due to heat
Place near the window to reduce the chill you feel near windows or by your feet.
(1) Window Glass Insulation Pannel N M
(Size: 1 sheet of 190 cm in width × 35 cm in height)
(2) Window Glass Insulation Pannel N L
(Size: 1 sheet of 190 cm in width × 55 cm in height)
Shut out the cold simply by attaching to your curtains.
(1) Insulated Window Glass Insulation Curtain M, Ultra Transparent
(Size: 2 sheets of 100 cm in width × 140 cm in length)
(2) Insulated Window Glass Insulation Curtain L, Ultra Transparent
(Size: 2 sheets of 100 cm in width × 225 cm in length)
Suppresses condensation on sash frames and keeps warm air inside
simply by affixing.
(1) Insulation Tape for Window Frames, Narrow Width, Silver / Brown / White
(Size: 2 rolls of 2 mm in thickness × 16 mm in width × 7 m in length)
(2) Insulation Tape for Window Frames, Wide, Silver / Brown / White
(Size: 1 roll of 2 mm in thickness × 40 mm in width × 7 m in length)
Prevents drafts coming through doors or partitions and
improves the effect of air-conditioning simply by affixing.
(1) Airtight Tape, 2 Rolls, Gray / Airtight Tape, 2 Rolls, Brown
(Size: 2 rolls of 10 mm in thickness × 15 mm in width × 2 m in length)
(2) Weather-Strip Tape for Doors
(Size: 1 roll of 1 mm in thickness × 40 mm in width × 92 cm in length)）
Absorbs and evaporates the dew condensation running down the window
by affixing to the bottom of the window glass.
-
Condensation Water Absorption Panel
(1) 250 mm: (amount of water absorption) approx. 600 g / individual package (2) 375 mm: (amount of water absorption) approx. 900 g / individual package -
Condensation Water Absorption Tape
(1) 10 m: (amount of water absorption) approx. 1300 g / individual package (2) Wide: (amount of water absorption) approx. 520 g / individual package (3) 4 m: (amount of water absorption) approx. 520 g / individual package -
Condensation Water Absorption Tape, Wide
Water absorption: approximately 320 g/package
By using insulation sheets and insulation tape around your windows,
the cold air coming in from the windows in the winter can be shut out.
It is possible to reduce the use of heating devices and reduce kerosene costs and CO2
by being more environmentally friendly and improving the efficiency of your indoor heating.
As shown by the graphs, CO2 emissions and the cost of kerosene over the course of one season both experience a reduction when comparing the effect of using Insulation Sheet to not using it . Insulation Sheet enables you to be kind to the earth and your wallet.
We calculated the reduction in the amount of kerosene and CO2 from a coefficient of overall heat transmission when the insulation sheet is affixed to the windowpane.
These are calculated values such as improvement values. They are not guaranteed values.
<Measurement conditions>
Outside temperature of 3 ℃, indoor temperature of
23 ℃, glass area of 16.2 m2, heating period of 10 hours
for 100 days, kerosene cost of JPY 120 / L
Attaching the film with double-sided tape on the window frame creates
a double-glazed structure, and the air layer keeps heat in and insulates, thus saving energy.
Also, by putting silica gel inside, the air inside is dried, thoroughly preventing dew condensation from forming.
Condensation is the phenomenon in which water vapor in the air condenses due to a decrease in temperature, forming water droplets.
By installing a dew condensation prevention sheet and a sash frame insulation sheet, a layer of air is created between the room and
the window and sash frame, preventing the outside air from directly cooling the water vapor in the room.
As a result, it is possible to suppress the occurrence of condensation.
Blocks the convection of the air cooled
by the window and shuts out the cold air
that flows in by one’s feet.
By installing panels and liners here,
the temperature of the window can be increased by 1.5 to 2.5 ℃.
